附录(钢管与保温层面积、体积计算表。预算定额) | ||||||||||||||||||||||
一、钢管与保温层表面积计算表 单位:㎡/m | 钢管与保温层表面积计算表 单位:㎡/m | |||||||||||||||||||||
管 道 公 称 直 径(mm) |
|
Dg | 管 道 公 称 直 径(mm) | |||||||||||||||||||
15 | 20 | 25 | 32 | 40 | 50 | 70 | 80 | 100 | 125 | 150 | 200 | ∫ | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 700 | ||
0.0669 | 0.0842 | 0.1053 | 0.1329 | 0.1508 | 0.1885 | 0.2372 | 0.2781 | 0.3581 | 0.4398 | 0.5184 | 0.688 | 保温层厚度(mm) | 0 | 0.8577 | 1.021 | 1.1844 | 1.3383 | 1.5017 | 1.665 | 1.9823 | 2.262 | |
0.1257 | 0.1429 | 0.164 | 0.1916 | 0.2095 | 0.2472 | 0.2959 | 0.3368 | 0.4169 | 0.4986 | 0.5771 | 0.7468 | 5 | 0.9164 | 1.0798 | 1.2431 | 1.3971 | 1.5604 | 1.7238 | 2.0411 | 2.3207 | ||
0.1587 | 0.1759 | 0.197 | 0.2246 | 0.2425 | 0.2802 | 0.3289 | 0.3698 | 0.4499 | 0.5316 | 0.6101 | 0.7797 | 10 | 0.9494 | 1.1128 | 1.2761 | 1.4301 | 1.5934 | 1.7568 | 2.0741 | 2.3537 | ||
0.1916 | 0.2089 | 0.23 | 0.2576 | 0.2755 | 0.3132 | 0.3619 | 0.4028 | 0.4829 | 0.5645 | 0.6431 | 0.8127 | 15 | 0.9824 | 1.1457 | 1.3091 | 1.463 | 1.6264 | 1.7898 | 2.1071 | 2.3867 | ||
0.2246 | 0.2419 | 0.263 | 0.2906 | 0.3085 | 0.3462 | 0.3949 | 0.4357 | 0.5159 | 0.5975 | 0.6761 | 0.8457 | 20 | 1.0154 | 1.1787 | 1.3421 | 1.496 | 1.6594 | 1.8228 | 2.1401 | 2.4197 | ||
0.2576 | 0.2749 | 0.2959 | 0.3236 | 0.3415 | 0.3792 | 0.4279 | 0.4687 | 0.5488 | 0.6305 | 0.7091 | 0.8787 | 25 | 1.0484 | 1.2117 | 1.3751 | 1.529 | 1.6924 | 1.8557 | 2.173 | 2.4526 | ||
0.2906 | 0.3079 | 0.3289 | 0.3566 | 0.3745 | 0.4122 | 0.4609 | 0.5017 | 0.5818 | 0.6635 | 0.742 | 0.9117 | 30 | 1.0813 | 1.2447 | 1.4081 | 1.562 | 1.7254 | 1.8887 | 2.206 | 2.4856 | ||
0.3566 | 0.3739 | 0.3949 | 0.4225 | 0.4405 | 0.4782 | 0.5268 | 0.5677 | 0.6478 | 0.7295 | 0.808 | 0.9777 | 40 | 1.1473 | 1.3107 | 1.474 | 1.628 | 1.7913 | 1.9547 | 2.272 | 2.5516 | ||
0.4225 | 0.4397 | 0.4609 | 0.4885 | 0.5064 | 0.5441 | 0.5928 | 0.6337 | 0.7138 | 0.7955 | 0.874 | 1.0436 | 50 | 1.2133 | 1.3766 | 1.54 | 1.694 | 1.8573 | 2.0207 | 2.338 | 2.6176 | ||
0.4885 | 0.5058 | 0.5268 | 0.5545 | 0.5724 | 0.6101 | 0.6588 | 0.6996 | 0.7797 | 0.8614 | 0.94 | 1.1096 | 60 | 1.2793 | 1.4426 | 1.606 | 1.7599 | 1.9233 | 2.0867 | 2.404 | 2.6836 | ||
0.5545 | 0.5718 | 0.5928 | 0.6205 | 0.6384 | 0.6761 | 0.7248 | 0.7656 | 0.8457 | 0.9274 | 1.0059 | 1.1756 | 70 | 1.3452 | 1.5086 | 1.672 | 1.8259 | 1.9893 | 2.1526 | 2.4699 | 2.7495 | ||
0.6205 | 0.6377 | 0.6588 | 0.6864 | 0.7043 | 0.742 | 0.7907 | 0.8316 | 0.9117 | 0.9934 | 1.0719 | 1.2416 | 80 | 1.4112 | 1.5746 | 1.7379 | 1.8919 | 2.0552 | 2.2186 | 2.5359 | 2.8155 | ||
0.6864 | 0.7037 | 0.7248 | 0.7524 | 0.7703 | 0.808 | 0.8567 | 0.8976 | 0.9777 | 1.0593 | 1.1319 | 1.3075 | 90 | 1.4772 | 1.6405 | 1.8039 | 1.9578 | 2.1212 | 2.2846 | 2.6019 | 2.8815 | ||
0.7524 | 0.7697 | 0.7907 | 0.8184 | 0.8363 | 0.874 | 0.9227 | 0.9635 | 1.0436 | 1.1253 | 1.2039 | 1.3735 | 100 | 1.5432 | 1.7065 | 1.8699 | 2.0238 | 2.1872 | 2.3505 | 2.6678 | 2.9474 | ||
